Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top

Thanks for your kindly hospitality. Your company is very professional , we will have nice cooperation in the near future.

—— Ruben Goroya

I'm Online Chat Now

Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top

Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top
Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top

Large Image :  Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top

Product Details:
Place of Origin: China
Brand Name: TOP
Model Number: T-0-0310
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiable
Packaging Details: 50-100pcs/bags, 5-50bags/carton and then packed in pallets
Delivery Time: within 10 days
Supply Ability: 500000pcs/day
Detailed Product Description
Industrial Use: Electronic Packing, Pc Board,IC Integrated Circuit Sealing And Handle: Self Adhesive ,heat Seal
Material: Laminated Material Material Structure: Apet/cpp Or Apet/cpe,
Color: Silver Semi Transparent Style Of Bag: Open Top/zip Lock/self-adhesive/guesset/cubic
Feature: Antistatic Printing: Could Be Printed According To Buyer's Requirement
Resistance: 10^8_10^11ohm Or 10^6-10^9ohm SIZE: 3X10INCH
High Light:

static dissipative bag

,

anti static pouch

3x10 Inch printed ESD Anti -Static Shielding Bags and rolls ROHS Certified



1. The kind of bag can keep static- sensitive components away from the potential static danger to the largest extent.its special four layer structure can create such effect as an inductive cover to separate the goods inside from the static field.



The inner layer is made from ethane which can remove the static and avoid static generation inside the bag.



this kind of hot seal bags is transparent,so the goods inside can be easily recoginzed from outside. surface resitance 10^8_10^11



4 layers:   Antistatic agent-polyester layer-aluminum shielding -anti-static polyethylene-Anti-static Layer.







Item Unit Test Standard
Metal layer resistance obm/sq.m <100
Metal layer optical transimission   40%-4
Surfac resisitivity ohm/sq <100
Time for static removal 5000-0v <0.01 second FTMS 101 B Method 4046
Friction static E1A541 Appendix CAvg Tribo electic Nanocoulombs Quartz<13n/inTefion,13n/in
Capacitance release Voltage difference -EA541 <10V
Anti- erosion FTMS 101C No visble spots FTMS 101 C Method 3005
Tensile Strength lbs./in ASTM D882 >18
Tear Initiation lbs./in ASTM D1004 >2.5
Puncture resistance P.S.I ASTM D3420 >100
Tear resistance lbs./in ASTM D882 >8
Oxygen barrier CC/100in-2/24hrs ASTM D3985<0.5
Heat seal temperature F 250-375
Heat seal pressure P.S.I 30-70
Breaking tensile force N/15mm GB/96-04-10
Breaking elongation rate % GB/96-04-10
Lamination strength N/15mm GB/96-04-10
Seal Strength N/15mm GB/96-04-10
Size GB/96-04-10 thickness +/-10%;length +/-3mm;width:+/-2mm



Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top 0

Waterproof Anti Static Bag 3x10 Inch Silver Semi Transparent Open Top 1
